Liv Pique Advanced 0

EFFICIENCY IS SPEED

Now 297g lighter*, the Advanced-grade composite frameset also features greater stiffness for efficient power transfer, a massive advantage on climbs and at speed. New FlexPoint Pro suspension minimises weight by minimising parts. And a shorter chainstay offers greater agility for manoeuvring switchbacks, and snappy acceleration for seizing every overtake opportunity. *Compared to previous generation

CONTROL IS POWER

With its patented, linkage-driven, single-pivot design, the new FlexPoint Pro suspension delivers 115mm of smooth, active rear-wheel travel, so you can maximise power and traction over ever-changing and uber-challenging terrain. Combined with a slacker head tube angle and 120mm of front suspension, this setup ensures you're equipped to dominate technical descents.

STABILITY IS MASTERY

Roll over just about anything on 29-inch wheels designed for stability and efficiency. Updated geometry provides a longer reach, putting you in a lower and more aggressive body position. A steeper seat tube angle increases pedalling efficiency on even the steepest climbs. And the modified cockpit includes a 35mm composite handlebar and alloy stem for steering precision.

Specification

• Sizes
  S
• Colours
  Gloss Mulberry Glitter/Black/Chrome
• Frame
  Advanced-grade composite front and rear triangles, 115mm FlexPoint Pro Suspension
• Fork
  Fox 34 Float SC Factory, 120mm, FIT4 damper, Boost 15x110 Kabolt, tapered, tapered, 44mm offset, 3 position remote lockout
• Shock
  Fox Float SL Factory 165x45, custom tuned for Liv
• Handlebar
  Giant Contact SLR XC, composite, 35mm
• Grips
  Liv XC Pro, 32mm
• Stem
  Giant Contact SL XC, alloy, 35mm
• Seatpost
  Fox Transfer dropper, remote 100mm travel / 30.9 x 345mm
• Saddle
  Fi'zi:k Vento Argo R5 with Kium Rail
• Pedals
  PEDALS NOT SUPPLIED
• Shifters
  SRAM AXS, 1x12
• Front Derailleur
  N/A
• Rear Derailleur
  SRAM XX Eagle, T-Type AXS
• Brakes
  Shimano XTR, hydraulic, Shimano RT-64 centerlock rotors [F]180mm, [R]160mm
• Brake Levers
  Shimano XTR BL-M9100
• Cassette
  SRAM XX CS 1299 SL T-Type, 10x52
• Chain
  SRAM XX T-Type
• Crankset
  SRAM XX SL T-Type, power meter, alloy chainring 32t, 55mm chainline
• Bottom Bracket
  SRAM DUB, press fit
• Rims
  ZIPP 1ZERO HiTop SL 29 WheelSystem, 30mm inner width
• Hubs
  XD, Centerlock
• Spokes
  Sapim
• Tyres
  Maxxis Aspen, 29x2.4, foldable, TLR, EXO, tubeless
• Extras
  Factory tubeless set up, custom Giant MRP chain guide, 3M clear foil down tube protector, max tyre size 2.4-inch, max chainring size 34t
• Weight
  The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Geometry
