Liv Lurra 2

Optimal Trail Design

Lightweight ALUXX SL-Grade Aluminium hardtail frame with a steep seat tube angle optimises your input when powering up climbs and hammering on the flats, resulting in greater efficiency and speed. And a 66-degree head tube angle offers confidence on steep descents, while the 438mm chainstays keep it feeling stable and playful. Frame sizes are paired up with wheel sizes, providing the ideal fit for you and where you want to ride.

Boosted Confidence

Take on technical terrain with the 130mm of plush front suspension, high-volume tubeless tyres offering extreme traction on roots, rocks and ruts, and a dropper seatpost allowing you to get low and ride with control.

Adventure-Ready

The Lurra comes equipped with mounts for two water bottle cages and additional mounts on the underside of the top tube allow riders to add a small gear bag for stowing tools. Internal cable routing keeps the important stuff tidy and protected, so you can stay focused on the ride ahead.

Specification

• Sizes
  For 27.5": XS, S For 29": S, M, L
• Colours
  Soap Suds
• Frame
  ALUXX SL-Grade Aluminium, 12x148 thru-axle
• Fork
  Giant Crest 34 RCL, 130mm, 15x110
• Shock
  N/A
• Handlebar
  Giant Contact TR35, alloy For 27.5": XS: 760mm, S: 760mm For 29": S: 760mm, M: 760mm, L: 780mm
• Grips
  Liv Sole-O
• Stem
  Giant Contact SL 35 For 27.5": XS: 40mm, S: 40mm For 29": S: 40mm, M: 50mm, L: 50mm
• Seatpost
  Giant Contact Switch dropper, remote For 27.5": XS: 100mm travel / 30.9 x 345mm S: 100mm travel / 30.9 x 345mm For 29": S: 100mm travel / 30.9 x 345mm M: 125mm travel / 30.9 x 395mm L: 150mm travel / 30.9 x 440mm
• Saddle
  Liv Sylvia
• Pedals
  platform
• Shifters
  Shimano Deore M4100, 1x10
• Front Derailleur
  N/A
• Rear Derailleur
  Shimano Deore M5120, Shadow +
• Brakes
  Tektro HDM 276, hydraulic, Tektro rotors [F]180mm, [R]180mm
• Brake Levers
  Tektro HDM 275
• Cassette
  Shimano Deore M4100, 11x46
• Chain
  KMC X-10
• Crankset
  Shimano Deore M5100, 30t For 27.5": XS: 170mm, S: 170mm For 29": S: 170mm, M: 170mm, L: 170mm
• Bottom Bracket
  Shimano, threaded
• Rims
  For 27.5": Giant AM 27.5, tubeless ready, sleeve-joint rim, 30mm inner width For 29": Giant AM 29, tubeless ready, sleeve-joint rim, 30mm inner width
• Hubs
  alloy, sealed
• Spokes
  Sapim
• Tyres
  For 27.5": Maxxis Ardent Race 27.5x2.6, EXO, TR, tubeless For 29": [F] Maxxis Minion DHF 29x2.5 WT, EXO, TR, tubeless, [R] Maxxis Aggressor 29x2.5 WT, EXO, TR, tubeless
• Extras
  For 27.5":Factory tubeless set up, max tyre size 2.6", max chainring size 32t For 29": Factory tubeless set up, max tyre size 2.5", max chainring size 32t
• Weight
  The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Geometry
