EnergyPak 400 battery system is ultra slim, delivering all the power you need, but in a smaller package that’s cleanly integrated into the lightweight composite frameset.
RideControl Ergo 3 remote attaches to the composite Giant Contact SLR integrated handlebar. The control can be mounted to either side of the handlebar so you can customise your controls for a clean, uncluttered cockpit.
New SyncDrive Pro Magnesium motor features a magnesium casing that reduces weight by 50g. It weighs just 2.5kg and delivers 85Nm of torque while retaining the instant engagement that characterises SyncDrive Pro motors. It’s also engineered for a reduced noise level and quiet performance.
S | M | L | XL | ||
---|---|---|---|---|---|
LOW | HIGH | LOW | HIGH | LOW | HIGH | LOW | HIGH | ||
A | SEAT TUBE LENGTH (mm) | 400 | 425 | 450 | 475 |
A1 | SEAT POST INSERTION DEPTH (mm) | 220 | 245 | 270 | 295 |
B | SEAT TUBE ANGLE | 77.2° | 78.0° | 76.0° | 76.7° | 76.0° | 76.7° | 76.0° | 76.7° |
C | TOP TUBE LENGTH (mm) | 577 | 575 | 607 | 605 | 636 | 634 | 665 | 663 |
D | HEAD TUBE LENGTH (mm) | 95 | 100 | 115 | 130 |
E | HEAD TUBE ANGLE | 65.7° | 66.5° | 65.8° | 66.5° | 65.8° | 66.5° | 65.8° | 66.5° |
F | FORK RAKE (mm) | 44 | 44 | 44 | 44 |
G | TRAIL (mm) | 113.1 | 108 | 113.1 | 108 | 113.1 | 108 | 113.1 | 108 |
H | WHEELBASE (mm) | 1194 | 1195 | 1215 | 1212 | 1244 | 1244 | 1275 | 1275 |
I | CHAIN STAY LENGTH (mm) | 447 | 447 | 447 | 447 | 447 | 447 | 447 | 447 |
J | BOTTOM BRACKET DROP (mm) | 10 | 10 | 10 | 10 |
K | STACK (mm) | 607 | 601 | 611 | 605 | 625 | 619 | 639 | 633 |
L | REACH (mm) | 439 | 447 | 457 | 462 | 480 | 487 | 505 | 513 |
M | STAND OVER HEIGHT (mm) | 726 | 735 | 733 | 742 | 732 | 741 | 741 | 750 |
N | HANDLEBAR WIDTH (mm) | 780 | 780 | 780 | 780 |
O | STEM LENGTH (mm) | 40 | 40 | 50 | 50 |
P | CRANK LENGTH (mm) | 160 | 165 | 165 | 170 |
Q | WHEEL SIZE | 29" [F] 27.5" [R] | 29" [F] 27.5" [R] | 29" [F] 27.5" [R] | 29" [F] 27.5" [R] |
