FlexPoint rear suspension with a Crest FloTrac Lite shock delivers 130mm of smooth travel tuned specifically for lighter weight riders. Up front, the 140mm Crest TR Elite fork handles rocks, roots and ruts. Front and rear suspension both have minimal activating force, giving young riders smooth control and confidence on technical trails.
An ALUXX SL aluminium frameset with youth-specific trail geometry is combined with quality lightweight components to minimise weight and help young riders tackle challenging terrain. A new 24-inch TRA WheelSystem borrows key technologies from the proven adult TRA WheelSystem for improved climbing capabilities and quicker acceleration.
Giant TRA WheelSystem features WideGuard technology, resulting in lighter, stronger rims so riders can run lower tire pressures for better traction without the risk of tire punctures or rim damage. The youth-specific 24-inch wheels help smaller riders manoeuvre and tackle technical trails, while a dropper seatpost makes it easy to optimise riding position while climbing or descending.
One Size | ||
---|---|---|
A | Seat Tube Length (mm) | 320 |
B | Seat Tube Angle | 77.0° |
C | Top Tube Length (mm) | 500 |
D | Head Tube Length (mm) | 105 |
E | Head Tube Angle | 64.5° |
F | Fork Rake (mm) | 30 |
G | Trail (mm) | 119.2 |
H | Wheelbase (mm) | 1054.1 |
I | Chain Stay Length (mm) | 390 |
J | Bottom Bracket Drop (mm) | |
K | Stack (mm) | 534.6 |
L | Reach (mm) | 376.6 |
M | Stand Over Height (mm) | 641 |
N | Handlebar Width (mm) | 680 |
O | Stem Length (mm) | 40 |
P | Crank Length (mm) | 140 |
Q | Wheel Size | 24" |
